What the Proof Implies

The proof page covers the properties that are proved directly: functional correctness, integrity, and confidentiality. These are high-level properties that every OS should provide, that very few manage to provide, and that no OS has better evidence for than seL4.

But the seL4 proofs do more — the formal proof of functional correctness implies the absence of whole classes of common programming errors. Provided the proof assumptions are true, some of these excluded common errors are:

• No buffer overflows: buffer overflows are a classic security attack against operating systems, trying to make the software crash or to inject malicious code into the cycle. We have proved that no such attack can be successful on verified configurations of seL4.
• No null pointer dereferences: null pointer dereferences are another common issue in the C programming language. In applications they tend to lead to strange error messages and lost data. In operating systems they will usually crash the whole system. They do not occur in verified configurations of seL4.
• No pointer errors: in C it is possible to accidentally use a pointer to the wrong type of data. This is a common programming error. It does not happen in verified configurations of the seL4 kernel.
• No memory leaks: memory leaks occur when memory is requested, but never given back. The other direction is even worse: memory could be given back, even though it is still in use. Neither of these can happen in verified configurations of seL4.
• No arithmetic overflows or exceptions: humans and mathematics usually have a concept of numbers that can be arbitrarily big. Machines do not, they need to fit them into memory, usually into 32 or 64 bits worth of storage. Machines also generate exceptions when you attempt to do things that are mathematically undefined like dividing by zero. In the OS, such exceptions would typically crash the machine. This does not occur in verified configurations of seL4.
• No undefined behaviour: there are many static analysis and verification tools that check for the absence of undefined behaviour in C. Our proof explicitly checks that no such undefined behaviour occurs.

The list goes on. There are other techniques that can also be used to find some of these errors. Here, the absence of such bugs is just a useful by-product of the proof.

To be able to complete our proof of functional correctness, we also prove a large number of so-called invariants: properties that we know to always be true when the kernel runs. To normal people these will not be exciting, but to experts and kernel programmers they give an immense amount of useful information. They give you the reasons why and how data structures work, why it is safe to optimise and leave out certain checks (because you know they will always be true), and why the code always executes in a defined and safe manner.

So does seL4 have zero bugs? Yes, of course, and no, of course not. See the FAQ entry for that.

You can get even more out of the seL4 proofs for your system. For instance, using the integrity property, you can run large untrusted legacy code bases in your system that have no hope of being formally verified, and you can still get formal proofs about security aspects of the entire system. This is because the integrity property of seL4 guarantees that, if the system is set up correctly, the untrusted code cannot adversely affect the behaviour of separated trusted code. The page on how to use seL4 and the seL4 white paper have more examples on this general idea.

This is an incredibly powerful technique. Together with the principle of least privilege and the fine-grained capability system of seL4, you can build defence in depth into the architecture of your system to a degree that is hard to imagine with traditional operating systems. If done right, bugs in one part of the systems will be extremely hard or impossible to exploit in any other part of the system. A buffer overflow bug in the audio driver? Not a worry for safety or security. Maybe the sound will not work, but your critical components will. This is in stark contrast to privilege escalation scenarios that can happen in a monolithic OS, where some hapless application or library can make the entire system vulnerable to a remote network exploit.

Internalising this technique will lead you to build systems with clear protection boundaries, least privilege, and clearly defined communication channels. That alone already makes systems more robust and easier to analyse and understand.

You do not need to perform formal verification of your system or any additional code to profit from this property. You can use any other analysis technique to make informal arguments about the behaviour of the system and informally make use of the integrity isolation provided by seL4 to connect them. This will still give you more strength than with any other operating system.
