Use seL4 as a fast and secure RTOS
seL4 provides fast and secure OS kernel mechanisms that you can use on otherwise bare metal to build systems as you would with a small RTOS. You need to provide your own drivers or adapt them from other sources, and you are free to design your system however you want with minimal overhead and correctness guarantees for the mechanisms that seL4 provides. You can design your system directly on the seL4 API or use one of the existing tools and frameworks to get started quickly.
Use seL4 as a Hypervisor
You can use seL4 as a hypervisor to virtualise other guest operating systems such as Linux. Generally, you would use one of the existing seL4 virtual machine monitors for this, or write your own. You can use seL4 to restrict resources for virtual machines, or pass them through. Most of the virtual machine monitor code is a library component that runs in user mode. That means, bugs in the virtual machine monitor can be contained to a single virtual machine (VM) and cannot propagate to the rest of the system.
Use seL4 as Hypervisor and RTOS at the same time
Since virtual machine monitors are just user space components like any others on seL4, you can freely run native seL4 user components next to or in communication with virtual machines. This can be an extremely powerful mix, enhancing and controlling what virtual machines can do. For instance, you could run legacy code in one VM, use a complex Linux driver in a separate driver VM, and connect them via a native cryptography components and network filter. The legacy code may still have bugs, but they cannot affect the crypto component. The complex driver may still have bugs, but it also cannot affect the crypto component – at most it can provide invalid input. The legacy code might be vulnerable to buffer overflow attacks, but the network filter could check input before it reaches any legacy code. And the system architecture in conjunction with seL4 can guarantee for you that the filter cannot be bypassed.
Use seL4 to architect Secure Systems
You can use seL4 to build systems that have security designed-in from the ground up. Think which security properties are the most important to guarantee. Design the architecture of your system such that these properties are guaranteed by the structure of the system and possibly a small number of small, trusted components that can be thoroughly analysed or even formally verified. seL4 and verified user-level system initialisation can give you that the architecture you have designed is in fact the architecture that is running in your system, and that the boundaries and communication channels of that architecture are enforced.
You can use components such as filters, sanitisers, authentication, integrity protection, secrets store, cryptography, etc to reduce trust and analysis effort to the places that matter. Context switching in seL4 is seriously fast – you can afford a lot more components and protection domains than you would in other systems.
This leverages the strong formal verification of seL4 without needing any specific formal verification expertise. If you do want to apply further formal verification to the system, you can now verify small parts of the system to gain system-global security properties.
Even without further analysis and verification, the system benefits from a componentised security architecture by being easier to understand and communicate about. Knowing which parts of the system are security critical and which are not, and being sure that uncritical parts cannot destroy security enables you to move fast without breaking things.
You can also leverage the formal verification of seL4 to speed up debugging and failure analysis during development: you know the verified code didn’t fail, and isolation wasn’t broken. This means you can focus your analysis on much fewer lines of code when something goes wrong.
Use seL4 for Cyber Retrofit
Imagine a heap of legacy code and a mandate to make it secure. Putting it behind a firewall will not make it secure, and there is no time for rewriting it from scratch. What can you do? Chances are that you can use seL4 for an incremental cyber retrofit.
If the security property you need can be enforced by green-field design with the right architecture, you likely can gradually restructure the legacy code base into a more and more secure system. You don’t need to reach that green-field system, you only need to reach an architecture that enforces the security property.
The first step is to put the complete legacy system into a virtual machine (VM) running on seL4. This in itself adds no security, only some overhead, but it serves as a starting point for incremental modularisation.
The next step is to extract and isolate coarse-grained subsystems, moving from a system with a single VM to one with multiple communicating VMs. For instance, if you want to protect against network attacks, you might move the network stack into a separate VM. If there is encryption involved, that could be a separate VM as well. Now you already have a much stronger system — a random buffer overflow in the rest of the code base can no longer be used to subvert the encryption code, and neither can a code-level attack on the network stack.
You could stop here, or repeat this process and refine until you have reached the level of assurance you require. You can also start removing VMs and replacing them with faster native seL4 components, or add filters, sanitisers, runtime checking, monitoring, attestation, and other components into the mix to guard input and output of legacy code bases.
This process has been used successfully to increase security for multiple systems. It does not work for all scenarios, but when it works, it shines.
There is a research article and a slide set with more information on how this works.
Use seL4 for Mixed Criticality
seL4 is ideally suited for mixed-criticality systems where critical code runs next to less critical, but maybe performance hungry code on the same system.
You can use seL4’s memory isolation for keeping untrusted code in check and seL4’s mixed-criticality scheduling for guaranteeing that untrusted code cannot deny service to critical components.
Use seL4 as the basis for your OS
seL4 is a microkernel, it is not an operating system. But you can use it as the basis for an OS – that is what it is designed for. There are existing OSes that do just that: the commercial KOS from Kry10 for dynamic systems and the open-source LionsOS from UNSW for static systems.
Use seL4 for fun and learning
There was a time when it was hard to get started with seL4. No longer.
Fire up Microkit and immediately get going on a simulator, or check out the seL4 Dev Kit guide on how to get started with hardware.
Use seL4 to hone your embedded systems skills, hack C or Rust code in seL4 user space, or any of the other supported languages, write something cool, tell people about it!
